serv-Clip Type 2

Pipe measuring point serv-Clip ® Type 2 (for mounting on non pressurized pipes)


This is what you can do instantaneously:

  • Measure pressure

  • Take oil samples

  • Bleed lines / Install pressure gauges

  • Install pressure sensors or pressure switches

  • Carry out particle measurements according to ISO or NAS-classes

  • Install flow filters



Installation from fluid-Check® Sensors and other with G 3/8":

  • fluid-Check Flow rate

  • Leakage

  • Temperature

  • Pressure

  • Aqua (in 2012 new!)



Advantages!

  • Quick and cheap installation (only 3 minutes)

  • Minimal downtime

  • No need to cut tubes

  • No cleaning necessary

  • No competition in the market!

  • No contamination



Technical data



  • For installation on steel and (*)stainless steel pipelines

  • For diameters:

  • from 10 - 42 mm /Tube 3/8" -  2" / Pipe ¼" to 3"

  • Working pressure up to 630 bar (9100 psi)

  • Working temperature from -40°C to +120 °C

  • Viton O-Ring in leak proof clamp (200°C)

  • Incl 3/8"screw and valve M16x2

  • (*)Up to 5mm with special needle Art.Nr.501-040-02 possible

  • Pipe measuring point serv-Clip® Type 1 (for mounting on non pressurized pipes) with 3/8" screw For hydraulic and gear oils

  • Installation of Sensors in few minutes -  no cutting pipelines- Installation with jaw/screw wrench only

Hydraulic pipe measuring point serv-Clip® Type 1 (for mounting on pressurized pipes)

How it works?

A needle is pressed through the wall of the pipe. It uses the principle of plastic deformation to create a leak-proof opening.
